(XGS2220-54FP) SWITCH (สวิตซ์) Zyxel XGS2220 Series 48G/2(10G) PoE++/4SFP+
฿90,907.00
ติดต่อสอบถามราคาพิเศษ
Line: @greatocean
Tel.: 099-495-8880
Facebook: https://www.facebook.com/gtoengineer/
Email: support@gtoengineer.com
**กรุณาสอบถามสินค้าก่อนกดสั่งซื้อทุกครั้ง
**กรณีสินค้าหมด หรือสินค้าไม่ใส่ราคา กรุณาติดต่อสอบถาม
**สินค้าโปรเจคโปรดติดต่อเราเพื่อขอราคาพิเศษ**
Out of stock
SKU : XGS2220-54FP Switch Zyxel GbE Layer 3 Access with 10GbE Uplink (XGS2220-54FP) Model XGS2220-54FP
Product name 48-port GbE L3 Access PoE+ Switch with 6 10G Uplink (960 W)
Layer 2+ Layer 3 Access
Total port count 54
100/1000 Mbps 48
1G/2.5G/5G/10G Ethernet (RJ-45) 2
Gigabit SFP –
1G SFP/10G SFP+ 4
PoE ports 50
Total PoE budget (watts) 960
IEEE 802.3at (PoE+) Port 1-40
IEEE 802.3bt (PoE++, 60 W) 100/1000 Mbps: Port 41 – 48 , 1G/2.5G/5G/10G: Port 49 – 50
Switching capacity (Gbps)
216
Forwarding rate (Mpps)
161
Packet buffer (byte) 2 M
MAC address table 32 K
Jumbo frame (byte) 9 K
L3 forwarding table Max. 1 K IPv4 entries , Max. 512 IPv6 entries
Routing table 64
VLAN routing Yes
IP interface 32
Flash/RAM (MB) 64 MB/1 GB
Power Input 100 – 240 V AC, 50/60 Hz
Max. power consumption (watt) 1161.6
Dimensions (WxDxH) (mm) 441 x 330 x 44
Weight (kg) 5.0 KG
| Interface | 48x 100/1000 Mbps 2x 1G/2.5G/5G/10G Ethernet (RJ-45) 4x 1G SFP/10G SFP+ |
|---|---|
| PoE Ports | Port 1-40: IEEE 802.3at (PoE+) Port 41 – 48: 100/1000 Mbps Port 49 – 50: 1G/2.5G/5G/10G (IEEE 802.3bt (PoE++, 60 W)) Total PoE Budget: 960W |
| Flash/RAM | 64 MB/1 GB |
| Throughput | 161 Mpps |
| Switch capacity | 216 Gbps |
| MAC Table address | 32k |
| AC voltage | 100 – 240 V AC, 50/60 Hz |
| Dimension (WxDxH) | 441 x 330 x 44 |
| weight | 5.0 kg |
| Warranty | 3 years |
