[RT-AC1500UHP]AC1500UHP AC1500 Dual Band WiFi Router

Model Name
RT-AC1500UHP
Network Standard
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
IPv4
IPv6
Data Rate
802.11a: สูงสุด 54 Mbps
802.11b: สูงสุด 11 Mbps
802.11g: สูงสุด 54 Mbps
802.11n: สูงสุด 600 Mbps
802.11ac: สูงสุด 867 Mbps
Antenna
External antenna x 4
Transmit/Receive
เทคโนโลยี MIMO
2.4GHz 4×4
5GHz 2×2
Processor
74Kc MIPS processor with 64 KB I-Cache and 32 KB D-Cache, targeted to operate at up to 775 MHz
Memory
16 MB Flash, 128 MB RAM
Boosts speed
Beamforming: 802.11ac Explicit transmit beamforming (TxBF) and Legacy implicit TxBF for both beamformer and beamformee
256-QAM high data rate
20/40/80 MHz bandwidth
Operating Frequency
2.4G Hz / 5 GHz
Ports
RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 4
USB 2.0 x 1
Button
WPS Button, Reset Button, Power Button
LED Indicator
Power x 1
Wi-Fi x 2
WAN x 1
USB x 1
LAN x 4
Power Supply
AC Input : 100V~240V(50~60Hz)
DC Output : 12 V with max. 1.5 A current
Package content
RT-AC1500UHP Gigabit Wi-Fi Router
RJ-45 Cable
Quick Start Guide
Power Adapter
Warranty Card
Product Weight (g)
348 g
Router APP
ใช่
Parental Control
ใช่
Traffic Control
Maximum Bandwidth limiter rule : 32
Traditional QoS
Maximum Traditional QoS rule : 32
ใช่
Traffic analysis period : Daily, Weekly, Monthly
Wireless
Wi-Fi Encryption : Open system, WPA/WPA2-Personal, WPA/WPA2-Enterprise
Maximum Guest Network rule : 2.4GHz x3, 5GHz x3
Guest Network Connection time limit
Guest Network Encryption : Open system, WPA/WPA2-Personal
Maximum MAC filters : 64
ใช่
WAN
Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
Maximum port forwarding rule : 64
Maximum port triggering rule : 32
ใช่
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay
LAN
ใช่
Maximum manually assign IP address rule : 64
VPN
VPN Client OVPN
VPN Server OVPN
ใช่
USB application
File System : FAT16, FAT32, NT3G, ext2, ext3
ใช่
Administration
Operating mode : Accesspoint, Mediabridge, Router
Operating system : ASUSWRT
Maximum Firewall keyword filter : 64
Maximum Firewall network service filter : 32
Maximum Firewall URL filter : 64
ใช่
