MASTERBOX NR200P BLACK [MCB-NR200P-KGNN-S00]

Model Number MCB-NR200P-KGNN-S00
Series MasterBox Series
Size Mini ITX
Color(s) Black
Materials Steel, Plastic, Mesh, Tempered Glass
Dimensions (L x W x H) 376 x 185 x 292mm incl. Protrusions, 360 x 185 x 274mm excl. Protrusions
Volume 18.25L (exlc. Protrusions)
Motherboard Support Mini DTX, Mini ITX, Max MB size: 244 x 226mm (L x H)
Expansion Slots 3
5.25″ Drive Bays 0
3.5″ Drive Bays 1 (Max. 2)
2.5″ / 3.5″ Drive Bays (Combo) 1
2.5″ Drive Bays 2 (Max. 3)
I/O Panel 2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic)
Pre-installed Fans – Top 2x 120mm 650-1800RPM PWM (SickleFlow)
Pre-installed Fans – Front N/A
Pre-installed Fans – Rear N/A
Pre-installed Fans – Bottom N/A
Fan Support – Top 2x 120mm
Fan Support – Rear 1x 92mm
Fan Support – Bottom 2x 120mm (recommended slim fans for GPUs wider than 2.5 PCI slots)
Fan Support – Side 2x 120/140mm
Radiator Support – Top N/A
Radiator Support – Rear 92mm (Not Compatible with Vertical GPU Installation)
Radiator Support – Bottom 120mm, 240mm, (recommended for custom loops only)
Radiator Support – Side 120mm, 140mm, 240mm, 280mm, (not compatible with vertical GPU installation)
Clearance – CPU Cooler 76mm (GPU in vertical position), 153mm (tempered glass side panel), 155mm (vented steel side panel)
Clearance – PSU 130mm
Clearance – GFX L: 330mm (incl. power connector), H: 156mm (incl. power connector), W: 60mm (triple slot)
Dust Filters Top, Bottom, Left side, Right side
Power Supply Support SFX, SFX-L
Warranty 2 years
Weight 5.93 kg
Accessories 1x PCIe 3.0 x16 riser cable
Note Single slot water-cooler GPUs or vertically mounted GPUs are recommended when using bottom radiator position, This product is only compatible for devices that support the PCI-E 3.0 specification. If you use this product with a motherboard that supports PCI-E 4.0, please enter into BIOS option and select PCI-E 3.0 before installation.
