MAINBOARD (เมนบอร์ด) MSI PRO Z790-P WIFI (SOCKET LGA 1700) (ATX)
฿7,400.00
ราคาสินค้าไม่รวมภาษีมูลค่าเพิ่ม
ติดต่อสอบถามราคาพิเศษ
Line : @greatocean
Tel : 099-495-8880
Facebook : https://www.facebook.com/gtoengineer/
Email : support@gtoengineer.com
Description
| Product Type | Mainboard |
| Brand | MSI |
| Model | PRO Z790-P WIFI |
| Socket | 1700 (12th Gen – Alder Lake) , 1700 (13th Gen – Raptor Lake) , 1700 (14th Gen – Raptor Lake Refresh) |
| Wattage | 150W |
| Chipset | Intel Z790 |
| Series | Celeron , Core i3 , Core i5 , Core i7 , Core i9 , Pentium |
| Slot | 4 |
| Memory Type | DDR5 |
| Max. Capacity | 128 GB |
| Speed | 4800 , 5000 , 5000 (OC) , 5200 , 5200 (OC) , 5400 , 5400 (OC) , 5600 , 5600 (OC) , 5800 (OC) , 6000 (OC) , 6200 (OC) , 6400 (OC) , 6600 (OC) , 6800 (OC) , 7000 (OC) |
| Graphic | Integrated Graphics Processor (Depends on CPU) |
| Audio | Realtek ALC897 |
| Audio Detail | 7.1-Channel High Definition Audio |
| SATA 2 | – Port |
| SATA 3 | 6 Port |
| RAID | RAID 0, 1, 5, 10 for NVMe Storage RAID 0, 1, 5, 10 for SATA Storage |
| M.2 | 4 x M.2 Slot(s) — • M.2_1 (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280/2260/2242 devices • M.2_2 (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices • M.2_3 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices • M.2_4 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices Port |
| Details | No |
| Slot | 1 x PCIe 3.0 x1 Slot , 1 x PCIe 3.0 x16 Slot , 1 x PCIe 4.0 x16 Slot , 1 x PCIe 5.0 x16 Slot |
| LAN | Intel 2.5Gb Ethernet |
| LAN Speed | 100/1000/2500 Mbps |
| Wireless | Wi-Fi 6E (802.11ax) Bluetooth 5.3 |
| USB 2.0 | 4 Port |
| USB 3.0 | – Port |
| USB 3.1 | – Port |
| Serial | – Port |
| USB 3.2 | 2 x USB 3.2 Gen 1 Type-A 1 x USB 3.2 Gen 2 Type-A 1 x USB 3.2 Gen 2×2 Type-C Port |
| D-Sub (VGA) | – Port |
| DVI | – Port |
| HDMI | 1 Port |
| DisplayPort | 1 Port |
| Audio | 6 Port |
| PS/2 | 1 (Keyboard/Mouse combo) Port |
| Additional | 1 x Flash BIOS button 2 x Wi-Fi Antenna connectors |
| LAN | 1 Port |
| Form Factor | ATX |
| Power Connector | 24 + 8 + 8 Pin |
| Dimension | 30.5 x 24.4 cm |
| การรับประกัน | 3 Years |
Additional information
| Product Type | Mainboard |
|---|---|
| Brand | MSI |
| Model | PRO Z790-P WIFI |
