(iDS-7316HQHI-M4/S) Hikvision DVR 16-ch 1080P 1.5U H.265 AcuSense DVR
ติดต่อสอบถามราคาพิเศษ
Line : @greatocean
Tel : 099-495-8880
Facebook : https://www.facebook.com/gtoengineer/
Email : support@gtoengineer.com
**กรุณาสอบถามสินค้าก่อนกดสั่งซื้อทุกครั้ง
**กรณีสินค้าหมด หรือสินค้าไม่ใส่ราคา กรุณาติดต่อสอบถาม
| Category | Details |
|---|---|
| IP Video Input | 8-ch (up to 24-ch) |
| 16-ch | BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
| HDTVI Input | 3K(2960 x 1665)@20 fps, 5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@30 fps, 4 MP(2560 × 1440)@25 fps,1080p@30 fps, 1080p@25 fps,720p@30 fps, 720p@25 fps |
| CVBS Output | 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| HDMI Output | 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Audio Input | 4-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Audio Output | 2-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio | 1-ch, RCA (2.0 Vp-p, 1 KΩ, independent) |
| Encoding Resolution | When 1080p Lite mode is not enabled: |
| 3K lite/4 MP Lite/1080p/720p/VGA/WD1/4CIF/CIF; | When 1080p Lite mode is enabled: |
| Frame Rate | Main stream: |
| Frame Rate | When 1080p Lite mode not enabled: |
| Frame Rate | For 3K stream access: 3K lite@12fps;4 MP lite@15fps/1080pLite@20fps;720p/WD1/4CIF/VGA/CIF@20fps |
| Frame Rate | For 5 MP stream access: 5 MP lite@12fps;4 MP lite@15fps/1080pLite@20fps;720p/WD1/4CIF/VGA/CIF@20fps |
| Frame Rate | For 4 MP stream access: 4 MP lite@15fps/1080pLite@25fps (P)/30fps (N) ;720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) |
| Frame Rate | For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) |
| Frame Rate | For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) |
| Frame Rate | When 1080p Lite mode enabled: |
| Frame Rate | 3K lite/5 MP lite@12fps;4 MP lite@15fps;1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) |
| Frame Rate | Sub-stream: |
| Frame Rate | WD1/4CIF@12fps; CIF@25fps (P)/30fps (N) |
| Serial Interface | RS-232, RS-485 (full-duplex), Keyboard |
| USB Interface | Front panel: 2 × USB 2.0 |
| USB Interface | Rear panel: 1 × USB 3.0 |
| Consumption | ≤ 55 W (without HDD) |
| Working Temperature | -10 °C to +55 °C (+14 °F to +131 °F) |
| 10% to 90% | Dimension (W × D × H) |
| 10% to 90% | 440 × 399 × 72 mm (17.3 × 15.7 × 2.8 inch) |
| Weight | ≤ 5 kg (without HDD, 11.0 lb) |
| PRODUCT TYPE | DVR |
|---|---|
| BRAND | HIKVISION |
| Series | Ultra Series |
| Model | iDS-7316HQHI-M4/S |
