HAF 700 EVO White [H700E-WGNN-S00 ]

Model Number H700E-WGNN-S00
Exterior Color Titanium Grey
Materials – Exterior Mesh, Steel, Plastic
Materials – Left Side Panel Tempered Glass, Steel
Dimensions (L x W x H) 556 x 279 x 540 mm (Body Size), 666 x 291 x 626 mm (incl. Protrusions)
Motherboard Support Mini ITX, Micro ATX, ATX, E-ATX, SSI CEB, SSI EEB
Expansion Slots 8
5.25″ Drive Bays N/A
2.5″ / 3.5″ Drive Bays (Combo) 12
2.5″ Drive Bays 12
I/O Panel – USB Ports 1x USB 3.2 Gen 2 Type C, 4x USB 3.2 Gen 1 (3.0)
I/O Panel – Audio In / Out 1x 3.5mm 4 Poles Audio Jack, 1x 3.5mm Mic Jack
I/O Panel – Other 1x LED Controller A1 (ARGB Gen 2), 1x ARGB/PWM Hub
Pre-installed Fans – Front 2x SickleFlow PWM Performance Ed. 200mm
Pre-installed Fans – Rear 2x SickleFlow PWM ARGB 120mm
Pre-installed Fans – Bottom 1x SickleFlow PWM ARGB 120mm
Fan Support – Top 2x 200mm, 3x 140mm, 6x 120mm (Remove 480mm bracket)
Fan Support – Front 2x 200mm, 3x 120/140mm
Fan Support – Rear 2x 120mm
Fan Support – Bottom 3x 120/140mm
Fan Support – Side 4x 120mm / 3x 140mm
Radiator Support – Top Up to 2x 360mm / 1x 420mm
Radiator Support – Front Up to 420/360mm
Radiator Support – Rear Up to 240mm
Radiator Support – Bottom Up to 420/360mm
Radiator Support – Side Up to 480/420mm
Clearance – CPU Cooler 166mm / 6.53 inch
Clearance – PSU 200mm / 7.87″
Clearance – GFX 490mm
Cable Routing – Behind Motherboard Tray 90-101mm
Included Accessories Vertical Graphics Card Holder V3 (Include 165mm PCIe 4.0 Riser Cable)
Dust Filters Front, Bottom, Side
Power Supply Support Bottom Mount, ATX
Warranty 2 years
Note * For regular 30mm thick radiators, for thicker please reference user manual.
Series HAF Series
Size Full Tower
