Product Specifications
Display
Diagonal Size	65″
Panel Type	ADS
Resolution	3,840 x 2,160
Pixel Pitch (HxV)	429.6(H)×429.6(V)
Brightness (Typ)	400 nit
Contrast Ratio	1,200:1
Viewing Angle (H/V)	178/178
Response Time	8ms
Color Gamut	72%
Glass Haze	25%
H-Scanning Frequency	135Khz
Maximum Pixel Frequency	78MHz
V-Scanning Frequency	60Hz
Contrast Ratio (Dynamic)	N/A
Operation Time Support	12/7
Connectivity
HDMI In	3
DP In	N/A
DVI In	N/A
Version of HDMI	2
Version of DP	N/A
Version of HDCP	2.1
Tuner In	N/A
USB	5 (2.0 X1, 3.0X4)
IR In	Yes
HDBaseT In	N/A
Audio In	Stereo Mini Jack
Audio Out	Stereo Mini Jack
Video Out	Yes
Power Out	N/A
RS232 In	Yes
RS232 Out	Yes
RJ45 In	Yes
RJ45 Out	Yes
WiFi	Yes
3G Dongle	N/A
Bluetooth	Yes
Power
Power Supply	AC100-240V 50/60Hz
Power Consumption (Off Mode)	N/A
Power Consumption (On Mode)	385W
Power Consumption (Sleep Mode)	0.5W↓
Dimension
Set Dimension (WxHxD)	1709 x 1020 x 88 mm
Package Dimension (WxHxD)	1863 x 1140 x 225 mm
Weight
Set Weight	45.5 kg
Package Weight	57.6 kg
Operation Conditions
Temperature	0℃~40℃
Humidity	10 ~ 90%
Mechanical Specification
VESA Mount	800 x 400 mm
Bezel Width	16.4mm(U), 16.4mm(L/R), 44.9mm(B)
Bezel Color	Space Gray
Frame Material	Non-Glossy
Optional Feature
Touch	Yes
Mount	N/A
Stand	N/A
SoC
OS Version	Android-11
Flash Memory Size	32G
Eco
Energy Efficiency Class	N/A
Certification and Compliance
EMC	Part 15, Subpart B Class A KS C9832, KS C9835 EN55032:2015/A11:2020/A1:2020,EN 55035:2017/A11:2020 EN 61000-3-2:2019/A1:2021 ?? ? ? ? ? ? EN 61000-3-3:2013/A1:2019/A2:2021 EN 61000-3-2:2019/A1:2021 ?? ? ? ? ? ? EN 61000-3-3:2013/A1:2019/A2:2021 EN 55035:2017/A11:2020 EN 61000-3-2:2019/A1:2021 ?? ? ? ? ? ? EN 61000-3-3:2013/A1:2019/A2:2021 J55032 , VCCI-CISPR32 JIS C61000-3-2 GB9254-2021 GB17625.1-2012 CNS13438 (ITE EMI) Class A /? AS/NZS? CISPR 32 EN55032:2015/A11:2020/A1:2020,EN 55035:2017/A11:2020
Safety	IEC 62368-1 Edtion 3&IEC 60950-1 UL62368-1 edition 3 GB4943.1-2022 PSB+ IEC 62368-1 NOM-019 K 62368 IRAM+ IEC 62368-1 EAC+ IEC 62368-1 INMETRO+ IEC 62368-1 SASO+ IEC 62368-1 BSMI+ IEC 62368-1 IEC 62368-1/AS/NZS 62368-1 IEC60950-1 / IS13252
