[4719072924942] MSI M/B MAG B660 TOMAHAWK WIFI [DDR5]

SKU : 4719072924942 MSI M/B MAG B660 TOMAHAWK WIFI [DDR5] CPU Socket Type Intel LGA-1700
CPU Type 12th Gen Intel Core Processors
Supported CPU Technologies Alder Lake
Chipset Intel B660
Number of Memory Slots 4x DIMM
Memory Standard DDR5 support up to 6200(OC) MHz
Maximum Memory Supported 128 GB
Expansion Slot 2x PCIe x16 slot, 1x PCIe 3.0 x1 slot
Storage Devices 2x M.2 Gen4 x4 slot, 1x M.2 Gen4 x2 slot, 6x SATA III port
Onboard Video Chipset Integrated Graphic on Processors
Onboard Audio Chipset Realtek ALC1220P Codec
Audio Channels 7.1 Channel HD Audio
Onboard LAN Chipset 1x Realtek RTL8125B-CG, 1x Intel Wi-Fi 6 module
Onboard LAN Speed 2.5 Gbps,
Real Panel Ports 1x HDMI, 1x DisplayPort, 2.5Gb LAN, 1x USB-C 3.2 gen2x2, Antenna Connector, HD Audio Jack
Onboard USB 1x USB-C 3.2 gen2 port, 1x USB 3.2 connector, 2x USB 2.0 connector
Dimensions W x D x H 30.5 x 24.4 cm
Case spec ATX Form Factor
Power Pin 1x 24-pin Main Connector, 2x 8-pin Power Connector
Warranty 3 Year
